required in OpenAPI (or Swagger)

· 3 min read
Serhii Hrekov
Serhii Hrekov
software engineer, creator, artist, programmer, projects founder

The meaning of required in OpenAPI (or Swagger) is consistent across all major versions: it specifies that a property must be present in the data payload. However, how you use and apply the keyword has evolved between versions.

OpenAPI 2.0 (Swagger 2.0)​

In Swagger 2.0, the required keyword is applied at the schema level, not directly on the property itself. It's a list that enumerates all required properties within that schema.

Example:

swagger: '2.0'
info:
  title: User API
  version: 1.0.0
definitions:
  User:
    type: object
    properties:
      id:
        type: integer
      name:
        type: string
      email:
        type: string
    required:
      - id
      - name

In this example, both id and name are required properties, but email is optional.

OpenAPI 3.0.0​

OpenAPI 3.0.0 maintains the same behavior for required but keeps the keyword within the properties block.

Example:

openapi: 3.0.0
info:
  title: User API
  version: 1.0.0
paths: {}
components:
  schemas:
    User:
      type: object
      properties:
        id:
          type: integer
        name:
          type: string
        email:
          type: string
      required:
        - id
        - name

The key difference here is a structural one: required is still a list of strings, but it's now nested under the components.schemas path, which is where schemas are defined in OA 3.0.

OpenAPI 3.1.0​

OpenAPI 3.1.0 aligns with the JSON Schema specification, so the meaning and placement of the required keyword are identical to the previous version. It's still a list within the schema definition.

Example:

openapi: 3.1.0
info:
  title: User API
  version: 1.0.0
paths: {}
components:
  schemas:
    User:
      type: object
      properties:
        id:
          type: integer
        name:
          type: string
        email:
          type: string
      required:
        - id
        - name

The distinction between OA 3.0 and 3.1 for required is minimal; the core concept and implementation remain the same, reflecting a continued commitment to standard JSON Schema behavior.

In summary, the functionality of required has been consistent: a property must be present in the payload. The main evolution has been the structural location of the required keyword as the specification matured from Swagger 2.0 to OpenAPI 3.x.
