Define a null property in OpenAPI

· 4 min read
Serhii Hrekov
Serhii Hrekov
software engineer, creator, artist, programmer, projects founder

To define a property that can be a string or null in OpenAPI (Swagger), you use different methods depending on the OpenAPI specification version.

OpenAPI 3.1.0​

OpenAPI 3.1.0 and later versions align with the JSON Schema specification, which simplifies the definition of nullable types. You can use an array for the type keyword to specify multiple possible types, including null.

Example:

openapi: 3.1.0
info:
  title: API
  version: 1.0.0
paths: {}
components:
  schemas:
    User:
      type: object
      properties:
        username:
          type: string
          description: A required string
        email:
          type: [string, "null"]
          description: Can be a string or null

In this example, the email property can be either a string or null. This is the most straightforward and modern way to define a nullable type in OpenAPI.

OpenAPI 3.0.0​

In OpenAPI 3.0.0, the nullable: true keyword was introduced specifically to define properties that can be null.

Example:

openapi: 3.0.0
info:
  title: API
  version: 1.0.0
paths: {}
components:
  schemas:
    User:
      type: object
      properties:
        username:
          type: string
          description: A required string
        email:
          type: string
          nullable: true
          description: Can be a string or null

In this version, you must specify the primary type (e.g., string, integer) and then add nullable: true to indicate that null is also a valid value. Do not use an array for type as it is not supported in this version.

OpenAPI 2.0 (Swagger 2.0)​

Swagger 2.0 does not have a dedicated nullable keyword or support for multiple types. The convention for defining a property that could be null was to document it in the description.

Example:

swagger: '2.0'
info:
  title: API
  version: 1.0.0
paths: {}
definitions:
  User:
    type: object
    properties:
      username:
        type: string
        description: A required string
      email:
        type: string
        description: Can be a string or null

For Swagger 2.0, the information that the email property is nullable is conveyed solely through the description field. This means that code generators and validation tools would not automatically enforce the nullability. It relies on the consumer of the API documentation to understand this convention.

The lack of a formal way to define nullability was one of the key reasons the nullable keyword was added in OpenAPI 3.0.0 to improve clarity and machine-readability of the specification.
