Generate FastAPI docs from msgspec.Struct json schema

FastAPI automatically generates documentation for msgspec.Struct models because msgspec provides a method to generate a JSON Schema for its structs. FastAPI and the underlying Pydantic library use JSON Schema to build the interactive API documentation (Swagger UI/OpenAPI). When you use a msgspec.Struct as a type hint in your endpoint, FastAPI calls msgspec to get the schema and incorporates it into the documentation.

---

How it Works

The process is seamless and requires no extra configuration. msgspec models are first-class citizens in FastAPI because of the shared reliance on the OpenAPI standard and JSON Schema.

Here's the sequence of events:

1. You define a data model using msgspec.Struct.
2. You use this model as a request body or response model in your FastAPI endpoint.
3. When FastAPI generates its OpenAPI schema, it inspects your function's type hints.
4. If it sees a msgspec.Struct, it calls msgspec.json.schema() to get the JSON Schema representation of that struct.
5. This schema is then embedded in the final OpenAPI documentation, which powers the interactive docs at /docs and /redoc.

Example

This example demonstrates how a msgspec.Struct is automatically converted into a detailed JSON Schema that appears in your FastAPI documentation.

import msgspec
from fastapi import FastAPI
from typing import Optional

# Define a msgspec.Struct model
class User(msgspec.Struct):
    name: str
    email: str
    age: Optional[int] = None
    is_active: bool = True

# Create the FastAPI app
app = FastAPI()

# Use the msgspec.Struct as a request body
@app.post("/users/")
def create_user(user: User):
    """
    Creates a new user with the provided data.
    """
    return user

# Run the application
# uvicorn main:app --reload

After you run this application and navigate to http://127.0.0.1:8000/docs, you will see a fully-formed API endpoint with a detailed schema for the User model, including fields, types, and default values.

The Generated Schema

Under the hood, when FastAPI generates its documentation, msgspec produces a schema similar to this:

{
  "properties": {
    "name": {
      "type": "string"
    },
    "email": {
      "type": "string"
    },
    "age": {
      "anyOf": [
        {
          "type": "integer"
        },
        {
          "type": "null"
        }
      ]
    },
    "is_active": {
      "type": "boolean",
      "default": true
    }
  },
  "required": [
    "name",
    "email"
  ],
  "title": "User",
  "type": "object"
}

This is the standard format that FastAPI understands and uses to render the interactive documentation. You can view the full OpenAPI schema yourself by navigating to http://127.0.0.1:8000/openapi.json.

Conclusion: The synergy between msgspec and FastAPI is a key benefit of using these libraries together. The documentation is a direct result of their shared commitment to the OpenAPI standard, making the process of generating accurate and useful API docs seamless.
